Image is for reference only , See Product Specifications
94871
| Manufacturers: | 3M |
|---|---|
| Product Category: | Terminals - Spade Connectors |
| Data Sheet: | 94871 |
| Description: | CONN SPADE TERM 14-16AWG #1/4 |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | 3M |
| Product Category | Terminals - Spade Connectors |
| Color | Blue |
| Series | Highland™ |
| Features | Butted Seam |
| Packaging | Bulk |
| Insulation | Insulated |
| Wire Gauge | 14-16 AWG |
| Part Status | Active |
| Termination | Crimp |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 1/4 Stud |
| Terminal Type | Spring, Snap |
| Contact Finish | Tin |
| Contact Material | Copper, ETP |
| Length - Overall | 1.100" (27.94mm) |
| Insulation Diameter | 0.170" (4.32mm) |
| Width - Outer Edges | 0.430" (10.92mm) |
| Length - Termination | 0.450" (11.43mm) |
| Material - Insulation | Vinyl |
| Tongue Inside Opening | - |
| Length - Ring Center to Termination | 0.400" (10.16mm) |
In Stock 0 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $0.16 | $0.16 | $0.15 |
Request Quote
