Image is for reference only , See Product Specifications
8309-8003
| Manufacturers: | 3M |
|---|---|
| Product Category: | D-Sub Connectors |
| Data Sheet: | 8309-8003 |
| Description: | CONN D-SUB RCPT 9POS PNL MNT IDC |
| RoHS status: | RoHS Compliant |
| Attribute | Attribute Value |
|---|---|
| Manufacturer | 3M |
| Product Category | D-Sub Connectors |
| Color | Gray |
| Series | 8300 |
| Features | Feed Through |
| Packaging | Bulk |
| Wire Gauge | 26-28 AWG |
| Part Status | Active |
| Termination | IDC, Ribbon Cable |
| Contact Form | - |
| Contact Type | Signal |
| Mounting Type | Panel Mount |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold |
| Flange Feature | Housing/Shell (4-40) |
| Number of Rows | 2 |
| Voltage Rating | - |
| Backset Spacing | - |
| Connector Style | D-Sub |
| Contact Material | Copper Alloy |
| Ingress Protection | - |
| Dielectric Material | Polybutylene Terephthalate (PBT), Polyester, Glass Filled |
| Number of Positions | 9 |
| Current Rating (Amps) | 1A |
| Operating Temperature | -55°C ~ 105°C |
| Shell Material, Finish | Steel, Tin Plated |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Material Flammability Rating | UL94 V-0 |
| Shell Size, Connector Layout | 1 (DE, E) |
In Stock 180 pcs
| Refrence Price ($) | 1 pcs | 100 pcs | 500 pcs |
|---|---|---|---|
| $7.37 | $7.22 | $7.08 |
